The ** Stanley Automatic Door MC521 Sensor Door Control Platform is a single platform suitable for all automatic door systems! This new-generation controller is newly designed for sliding and swing door systems. All functions¡ªdoor type, motor type, manual mode, speed, opening delay, troubleshooting¡ªcan be set easily and precisely via a Palm handheld device.

Technical Specifications and Brief Description
l Opening/closing type: double-leaf opposing sliding.
l Automatic door speed and load:
a) Max. opening speed: V=0.762 m/leaf/s; max. adjustable closing speed = 0.457 m/leaf/s; adjustable independently.
b) Open hold time: 0-30 seconds, adjustable.
c) System operating noise: less than 60 dB(A).
d) The automatic door operator load can reach 180 kg per leaf.

l The detector uses a microwave radar detector; detection range 2** x **0 x 2**.

l Power supply: AC 220V ¡À10%, 3A (power transformer included)

l Ambient Temperature, -20¡ãC¡«55¡ãC

l Provides different solutions for different applications;
l Overall installation and commissioning are simple and quick, fully meeting the fast pace of today's market competition;
l Diversified door designs offer customers different choices;
l A range of safety accessories provides the highest level of entrance safety;
l The MC521 control system makes door operation ** accurate; 18 adjustable parameters make operation ** user-friendly;
l The universality of the MC521 system **s service capability, and it also supports dual-motor drive;
l Can be seamlessly integrated with security monitoring systems.
l Concealed guidance function for a ** attractive and stable look;
l Simple glass installation enables the fastest and best installation and after-sales service;
l A ** localized after-sales service system provides the fastest and best support;
l Load-bearing wheel: made of advanced high-fluorine polyurethane material, highly chemical-resistant, water-resistant, extremely strong and wear-resistant;
l Belt material: chloroprene rubber with excellent elasticity, wear/chemical/aging resistance, operating temperature range -45¡ãC to +**¡ãC, non-flammable;
l Multiple control modes make operation ** convenient for users;
l Remote wireless commissioning via Bluetooth makes adjustment and repair easier and faster.

l Program controller:
1. Program settings can be completed without opening the housing, via a handheld programming device;
2. Operating parameters can be viewed via the handheld programming device;
3. Operating faults can be detected via the handheld programming device;
4. Program settings can also be completed manually without a handheld device, making commissioning ** intuitive and user-friendly;
5. Fault display with a friendly user interface; operating information at a glance (LED display);
6. Firmware upgrades of the control board can be done without replacing the controller;
7. Provides 3 independent signal output terminals;
8. Provides 2 emergency-stop input signals;
9. Can connect 2 sets of safety through-beam photocells at the same time, and anti-pinch light curtains can be installed;
10. Opening/closing speed and force can be adjusted separately;
11. Reverse-on-obstacle stop after two consecutive encounters;
12. Full motion detection and control for ** accurate and stable operation (closed-loop speed control);
13. Supports single- or dual-motor drive control.
